Course: Construction Terminology 101

Like all industries, construction uses its own brand of terminology and phrases. In any construction project, its a good idea to get a general knowledge of the concepts being displayed or conveyed. Did you know the following terms and definitions as they relate to architectural drawings (plans)?



Floor Plan: A drawing featuring a horizontal section of the project space. Imagine looking down on the project from above, this is the floor plan. A floor plan is also sometimes referred to as a floor layout.


Section (or cross section): This describes a drawing that shows a cut through of the body of a building or object (like walls or casework), perpendicular to the horizon line.


Detail: A detail is generally a close up of a section. The detail helps to visualize how a building, room, or object is to be constructed or connected.


Elevation: A drawing that shows a front or side view of a building or room. It is a 2D representation of the building or room it shows.


Dimension: The distance between two points


Site Plan (or plot plan): Similar to a floor plan, in that it is a drawing featuring the project space from above, but this plan includes exterior space. This is important information when a project includes work outside a building like a parking lot or landscape. New construction will always have a site plan.


How did you do? Did you pass Construction Terminology 101? Good news, everyone graduates from my classes.



You graduate! You graduate! Everyone graduates from Terminology 101
